Pallet stoppers fulfill two functions in the assembly of industrial and household goods on palette loop systems: They ensure smooth deceleration of individual or several palettes which have been parked in waiting positions at set line areas in the production process, and forward them individually for transporting to the next manufacturing position. There the palette stopper again ensures a smooth deceleration to avoid damage to the manufactured parts from hard impacts. At the same time it ensures the final position is reached precisely to guarantee correct machined assembly.
- Precise deceleration and separation of pallets
- Masses up to 450 kg and speeds up to 40 m/min
- Single acting: via return spring
- Double acting (optional): pneumatic return
- Housing: aluminium, black anodized
- Hardened stop, (Plastic stop for low masses, optional)
- Sensor for end position (optional)
- Special version: pallet stopper for clean room
- Cl. 5 (ISO), Cl. 100 (US), Cl. 3 (VDI)
